Product Specificatons
● Size : 56in(L)x28in(W)x38in～49in(H)
● Weight: 65kg (with battery,pallet)
● Speed : High-speed/Low-speed switchable
〔High speed setting〕3.6mi/h (Forward) • 1.2mi/h (Backward)
〔Low speed setting〕1.9mi/h (Forward) • 0.8mi/h (Backward)
● Max.Load capacity : 250kg
● Max.Climbing angle : Slope 12° (Max.Load capacity : 250kg)
● Pallet area : 41in～49in(L)x22in～34inl7in(W)
● Motor : Wheel motor 350W / RPM:85/min
(Overcurrent protection circuit)
● Brake system : Disc brake / Brake lever with stopper
● Frame : Low carbon steel
● Surface treatment: Powdered baking finish
● Front tire(2) : 13x5.00-6 (Pneumatic tire)
● Rear tire(2): 3.00-4 Caster type (No flat tire)
● Min.Tuming radius : 28in
● Battery : DC24V,12A Electrolyte lead storage battery
(Encapsulated type)
● Power switch key (3)
● Grip throttle speed adjustment (0 position automatic retractable)
● Forward/backward drive-shift switch Battery indicator
● Rapid charging function : (charging time : 8hours)
● Charger : (input) 100V～240V/50～60Hz (output) DC29V 1.7A
● Operating temperature range : 32°F～104°F
● Qty per 20'/40' M Container(pcs): 72/144
● Made in China
